18 inch 6 Axis FPV Drone 15-20kg payload with 5.8G 3W VTX F722 Flying Tower 10-20KM Long Distance Drone Kit

18 inch 6-Axis FPV Drone 15-20kg payload with 5.8G 3W VTX F722 Flying Tower 10-20KM Long Distance Drone Kit

Our FPV drones accept deep customization, If you need to change or upgrade the configuration, please let us know your needs!

Product parameters:
Payload: 8-20kg
Flying Time: With 18KG Load Flying Time: 20min; No Load: 40min
18inch FPV Drone Battery(Optional): 22000mAh 12S*2  (Two batteries connected in parallel)
Flying Distance: 10-20km
Max Speed: 130km/h（No load）；100km/h（Load）
Max Altitude: 5000m

Frame: 18 inch 6 Axis Carbon
Structure: Hexacopter Frame
Wheelbase: 980mm
Bottom Plate Thickness: 4mm
Top Plate Thickness: 3mm
Carbon Plate Material: T300/T700
Height of Electronic Device Layer: 30mm
carbon tube: 22mm
Camera Spacing: 20mm
Stack Mounting Hole: M3*30mm
VTX Mounting Hole: M2*19/19  M3*30*30mm /M2*22*22mm
Propeller Installation Size: Max 18 inch
Motor Mounting Hole: 21mm*21mm/34mm*34mm
Top Plate Size: 35*33cm
Bottom Plate Size: 32-30cm

Motor: 5020 230KV
Operating Rated Voltage: 8-12S
No-load Current: 1.6A
Motor Weight: 320g
Maximum Current: 77A
Maximum Power: 3579W
Motor Size: Ф62*58mm

Flight Control(FC): F722
Size: 36×36mm
Mounting Holes: 30.5×30.5mm
9V: 9V regulated power supply output interface, max current 2A
5V：5V regulated power supply output interface, maximum current 3A
4.5V：Receiver power connector (USB power supply only)
CR: Current monitoring port
M1: camera reference pin (according to the flight control firmware version)
VI: Camera input port
VO: Graphic output interface
LED: RGB light strip interface
B-: Connect to the negative terminal of the buzzer, positive terminal connects to B+
RC: Receiver SmartPort interface
Rssi: Rssi signal input port

ESC: 120A-12S
Continuous Current: 120A
BEC: No
Current Sensor: Yes
Battery Cells: 4-12S
Size: 46*30mm
Mounting Hole Spacing: 30.5*30.5mm

Camera: Manual Cam 1500TVL
Model: HD 1500TVL (upgraded version with OSD tuning board)
Image Sensor: 1 / 3′CMOS
Pixels: 1500TVL
Lens: 2.1mm
Signal System: PAL / NTSC (adjustable via OSD)
Signal-to-Noise Ratio: > 60Db（AGC OFF）
Electronic Shutter Speed: PAL: 1 / 50-100.000; NTSC: 1 / 60-100000
Electronic Shutter: PAL: 1/50 - 100000; NTSC: 1/60 - 100000
Automatic Gain Control(AGC): Low/ Medium/ High
Backlight Compensation(BLC): Yes
Minimum Illumination: 0.001Lux / 1.2F
WDR: D-WDR
DNR: 3DNR
Day/ Night: Auto/Color/B&W
Power Supply: DC 5V-30V

VTX: 4.9/5.8G 3W
Supported Voltage: 20-30V
BEC: 5V
Transmission Power: 25 / 1000mW; 2000mW / Max
Antenna Interface: MMCX
Output Power: 3W
Standard 9 Channels: A / B / E / F / R/L/O/U/H
Video Transmission Protocol: IRC
Mounting Holes: 20X20mm / M2
Size: 54mm × 28mm × 13mm
Weight: 32.5g

Antenna: 5.8G RHCP 150MM
*The whole is made of imported PC+ABS material which can withstand high strength impact.
*Impact resistant double-sheathed semi-rigid cable
*Root reinforcement design, 360 ° protection

RX: ELRS 915MHz
Processing Chip: ESP8285
RF Chip: SX1276IMLTRT
Power Input: 5V
Operating Current: 100mA
Operating Protocol: CSRF
Receiving Frequency Range: 915MHz or 868MHz
Size: 12mm;12mm;3mm
Weight: 0.6g (Antenna not included)
Antenna Connector: IPEX1
Telemetry Output Power: <17dBm
Firmware Update Method: WIFI

Propellers: 1710
Type: 1810
Blades: 3
Material: Fiberglass Nylon
Pitch: 10in
Center Hole lnner diameter: 5mm
Weight/g: 17g

Package weight: 6kg
Package size: 40*40*18cm

Note: Package does not include a remote control; batteries and a charger are optional.

**We are a source manufacturer and welcome bulk purchases! We also accept deep customization services for one unit. If you have any needs, please contact us!
