MX330T FPV Drone English User Manual

The MX330T FPV Drone is an AI high-speed flight platform developed by Skydroid. It has a high-strength carbon fiber body, with a long endurance of 35 minutes with an empty payload and up to 15 minutes under a load of 1.5KG. It can fly at high precision and speed, with a speed of up to 30m/s. Combined with the H12 Pro, it can achieve a 15KM control range and 1080P high-definition video/image transmission, as well as route planning, automatic execution, and AI dynamic tracking. The MX330T's dual light gimbal integrates a 2K high-definition visible light camera and a high-resolution thermal imaging camera, providing a clear field of view while also detecting heat sources.

MX330T Parameters：
Model: MX330T
Number of axes: 4-axis
Weight (without battery): 950g
Dimensions without propellers (L x W x H): 369 x 313 x 80.5mm
Dimensions with propellers (L x W x H): 578.5 x 528.7 x 80.5mm
Propeller size: 1050mm
Diagonal wheelbase: 430mm
Input voltage: 6S (26.1V)
Battery Capacity: 8000mAh
Battery Weight: 815g
Maximum Ascent Speed: 10m/s
Maximum Descent Speed: 10m/s
Maximum Horizontal Flight Speed (No Wind): 30m/s
Maximum Flight Endurance: 35min
Operating Temperature: 0-45°C
GNSS: GPS+GLONASS+Galileo
Operating Frequency: 5.8GHz
RF Power: Maximum 24dBm
Hovering Accuracy: Horizontal: ±1m (GPS Operation)
Maximum Image and Data Transmission Distance: 20km

Visible Light Camera Parameters:
Lens Pixels: 5MP
Lens Focal Length: f/3.5-4.75mm
Aperture: F2.0
HFOV/VFOV/DF Zoom: 100°/52°/122°
Zoom: 30x electronic zoom
Image transmission resolution: 1280*720
Video resolution for visible light SD card recording: 2560*1440
Video storage format: MP4
Photo resolution: 2560*1440
Photo storage format: JPEG
Supported memory card types: MicroSD (up to 256GB)
Supported file system: FAT32

Thermal imaging camera parameters:
Resolution: 384*288
Frame rate: ≤25Hz
Thermal time constant: <10ms
Focal length: 7mm
Aperture: F1.0
FOV: 24.8°*18.7°
Pixel pitch: 12μm
Spectral range: 8-14μm

MX330 FPV Drone Features：
CARBON FIBER FRAME：
MX330 FPV Drone using high-strength carbon fiber frame ensures durability and reduces weight, providing a robust structure that can withstand harsh environments and improve flight performance.

35 MIN ENDURANCE (UNLOADED)：
MX330 FPV Drone using a long endurance of 35 minutes when unloaded, the drone is ideal for extended missions without the need for frequent battery changes, enhancing efficiency in operations such as surveying and monitoring.

HIGH PRECISION & HIGH-SPEED FLIGHT：
MX330 FPV Drone Capable of flying at speeds up to 30m/s, this drone can quickly reach destinations, making it suitable for time-sensitive tasks. Its high precision ensures stable and accurate flight, critical for applications like mapping and inspections.

3KG PAYLOAD CAPACITY：
The MX330 FPV Drone can carry payloads of up to 3.0 kg and can be used in a variety of applications, including transporting cargo, medical supplies, or sensors, thereby expanding the range of drone missions.

20KM WORKING RANGE：
The extensive 20KM (M330T) working range allows for operations over large areas without losing control or transmission, making it perfect for large-scale agricultural monitoring, search and rescue missions, and infrastructure inspections.

2K RESOLUTION：
MX330 FPV Drone Equipped with a 2K high-definition camera, the drone provides clear and detailed images and videos, essential for applications requiring high-quality visual data such as inspection and surveillance.

THERMAL IMAGING：
The thermal imaging capability of the MX330 FPV Drone model allows for the detection of heat sources, which is invaluable in search and rescue operations, firefighting, and equipment inspections.

AI DYNAMIC TRACKING：
MX330 FPV Drone using AI dynamic tracking enables the drone to follow moving objects or people autonomously, enhancing its utility in surveillance, sports filming, and dynamic scene monitoring.

MX330 FPV Drone is a high-performance drone platform that combines advanced features with robust construction, making it suitable for a wide range of professional applications.

FLIGHT MODE-REMOTE CONTROL E CHANNEL CAN SWITCH FLIGHT MODE:
*Fixed altitude mode: In fixed altitude mode, the aircraft will automatically control thethrottle to maintain the same altitude. In a windy environment, the pilot needs toconstantly adjust roll and pitch to keep the aircraft stationary.

*GPS mode: In GPS mode, the aircraft will automatically maintain its current position.orientation, and altitude. Good GPS location, low electromagnetic interference fromthe compass, and low vibration are all veryimportant.

Attack mode: After successfully locking the target, switch to this mode, and the dronewill fly towards the target to attack. lf there is no target locked, this mode is equivalentto fixed altitude mode.
